14.95 USD

This manual can be used by anyone from a first time owner/amateur to a professional https://www.tradebit.comy to read type,And give you all the information needed to do the procedure https://www.tradebit.comp this service manual handy and use it often. Performing routine,preventive maintenance will save you time & money by helping to prevent premature failure and unnecessary repairs.

*****************
Models Covered:

Suzuki DF9.9 (1997-2000)
Suzuki DF15 (1997-2000)
Suzuki DF25 (1997-2000)
Suzuki DF30 (1997-2000)
Suzuki DF40 (1997-2000)
Suzuki DF50 (1997-2000)
Suzuki DF70 (1997-2000)

****************
Manual Contents:

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Notes, cautions and warnings / Torque specifications / Engine operation / Fasteners / Lubricants / Gasket sealants / Galvanic corrosion / Protection from galvanic corrosion / Propellers / Specifications

CHAPTER TWO / TOOLS AND TECHNIQUES
Safety first / Basic hand tools / Test equipment / Service hints / Special tips / Mechanic's techniques / Specifications

CHAPTER THREE / TROUBLESHOOTING AND TESTING
Outboard engine identification / Troubleshooting test equipment / Troubleshooting preparation / Starting difficulty / Fuel system / Starting system / Charging system / Ignition system / Warning system / Fuses and wire harness / Wire harness / Power head / Cooling system / Gearcase / Trim system / Electronic fuel injection / Specifications

CHAPTER FOUR / LUBRICATION, MAINTENANCE AND TUNE-UP
Before and after each use / Check engine oil level / Check for fuel and oil leaks / Engine mounting hardware inspection and torque / Propeller inspection / Cooling system flush / Routine power head maintenance / Engine oil change / Oil filter replacement / Timing belt inspection / Valve adjustment / Hoses and clamps inspection / Spark plug inspection / Throttle and shift linkage inspection / Fastener inspection / Timing and fuel system adjustments / Battery service / Power head anode inspection / Midsection maintenance / Swivel and tilt pin lubrication / Steering cable lubrication / Anode inspection / Ground wire inspection / Gearcase maintenance / Gearcase lubricant change / Propeller shaft and nut lubrication / Anode inspection / Storage preparation / Submersion / Corrosion maintenance / Tune-up / Ignition timing check / Compression check / Carburetor adjustment / On-boat testing / Specifications

CHAPTER FIVE / SYNCHRONIZATION AND ADJUSTMENT
Valve adjustment / Throttle cable and linkage adjustment / Shift cable and linkage adjustment / Carburetor synchronization (DF25 and DF30 models) / Pilot screw adjustment / Idle speed adjustment / Choke solenoid and choke linkage / Dashpot adjustment / Neutral-only start cable / Trim position sender / Trim tab / Specifications

CHAPTER SIX / FUEL SYSTEM
Fuel system service precautions / Low pressure fuel pump / Silencer cover / Carburetor removal and installation / Carburetor overhaul / Fuel injection system / Specifications

CHAPTER SEVEN / ELECTRICAL AND IGNITION
Starting system / Charging system / Ignition system / Warning system / Battery maintenance / Specifications

CHAPTER EIGHT / POWER HEAD
Flywheel / Power head removal/installation/repair / Cylinder head / Cylinder block component removal / Cylinder block disassembly / Cylinder block cleaning / Cylinder block inspection and maintenance / Cylinder block assembly / Break-in procedure / Specifications

CHAPTER NINE / GEARCASE
Gearcase shim selection / Gearcase shim adjustments / Specifications

CHAPTER TEN / MANUAL STARTER
Manual starter / Specifications

CHAPTER ELEVEN / HYDRAULIC TRIM AND MIDSECTION
Trim system / Midsection / Specifications

CHAPTER TWELVE / REMOTE CONTROL

INDEX

WIRING DIAGRAMS

****************
File Format: PDF
Compatible: All Versions of Windows & Mac
Language: English
Requirements: Adobe PDF Reader

---

Keywords: suzuki outboard df9.9 df15 df25 df30 df40 df50 df70 hp four strokes shop service manual;suzuki outboard df9.9 df15 df25 df30 df40 df50 df70 hp four strokes;suzuki outboard df9.9 df15 df25 df30 df40 df50 df70 hp;suzuki outboard
File Size: 18.2 MBytes
